LV-429003 - BASIC FRAME by SQUARE D
$165.10Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | ComPact NSX100...250 |
| Voltage withstand | 8 kVIEC 60947-2 |
| Voltage insulation | 800 V AC 50/60 Hz IEC 60947-2 |
| Poles | 3 |
| Utilization category | Category A |
| Ik degree of protection | IK07 conforming to IEC 62262 |
| Mounting | Fixed |
| Terminal pitch | 1.4 in (35 mm) |
| Connection surface top | Front |
| Connection surface bottom | Front |
| Pollution degree | 3 IEC 60664-1 |
| Depth | 86.36 |
All specifications
| Parameter | Value |
|---|---|
| Width | 104.14 |
| Height | 160.02 |
| Electrical life cycles | 10000 cycles 690 V AC 50/60 Hz In IEC 60947-2 20000 cycles 690 V AC 50/60 Hz In/2 IEC 60947-2 30000 cycles 440 V AC 50/60 Hz In IEC 60947-2 50000 cycles 440 V AC 50/60 Hz In/2 IEC 60947-2 |
| Mechanical life cycles | 50000 cycles IEC 60947-2 |
| Standards | EN/IEC 60947-2 UL 508 |
| Range | ComPact |
| IP rating | IP40 conforming to IEC 60529 |
| Control_type | Toggle |
| Frequency | 50/60 Hz |
| Network_type | AC |
| Package_type | PCE |
| Protection_type | Without protection |
| Safety category | F 36 kA 415 V AC |
| Application_type | Distribution |
| Supply voltage | 690 |
| Device short name | NSX100F |
| Breaking cap icu | 10 |
| Switching current | 100 |
| Storage temperature | -58...185 °F (-50...85 °C) |
| Circuit breaker name | Compact NSX100F |
| Suitability for isolation | Yes EN/IEC 60947-2 |
| Main_product_or_component_type | Basic frame |
| Operating temperature | -13 |
| Ordering and shipping details (Category) | US10DE201101 |
