Schneider Electric LV4-29639
MPNLV4-29639
Obsolete
LV4-29639 - 100AMP by MERLIN GERIN
$242.57Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Voltage withstand | 8 kV conforming to IEC 60947-3 |
| Voltage insulation | 800 V AC 50/60 Hz conforming to IEC 60947-3 |
| [Icm] rated Short-Circuit making capacity | 330 kA with upstream protection circuit breaker 2.6 kA switch-disconnector alone |
| Poles | 4 |
| Ik degree of protection | IK07 conforming to IEC 62262 |
| Mounting | Fixed |
| Terminal pitch | 35 mm |
| Connection surface top | Front |
| Connection surface bottom | Front |
| Pollution degree | 3 conforming to IEC 60664-1 |
| Depth | 86 |
| Width | 140 |
All specifications
| Parameter | Value |
|---|---|
| Height | 161 |
| Electrical life cycles | AC-22 A: 10000 cycles 250 V DC In/2 (1 pole) conforming to IEC 60947-3 AC-22 A: 15000 cycles 690 V AC 50/60 Hz In/2 conforming to IEC 60947-3 AC-22 A: 20000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-3 AC-22 A: 35000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-3 AC-22 A: 5000 cycles 500 V DC In (2 poles in series) conforming to IEC 60947-3 AC-22 A: 8000 cycles 690 V AC 50/60 Hz In conforming to IEC 60947-3 AC-23 A: 10000 cycles 250 V DC In/2 (1 pole) conforming to IEC 60947-3 AC-23 A: 15000 cycles 690 V AC 50/60 Hz In/2 conforming to IEC 60947-3 AC-23 A: 20000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-3 AC-23 A: 35000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-3 AC-23 A: 5000 cycles 500 V DC In (2 poles in series) conforming to IEC 60947-3 AC-23 A: 8000 cycles 690 V AC 50/60 Hz In conforming to IEC 60947-3 |
| Mechanical life cycles | 50000 cycles conforming to IEC 60947-3 |
| Standards | EN/IEC 60947-3 |
| Range | ComPact |
| IP rating | IP40 conforming to IEC 60529 |
| Control_type | Toggle |
| Network_type | AC DC |
| Package_type | PCE |
| Visible break | No |
| Supply voltage | 690 |
| Device short name | Compact NSX100NA |
| Switching current | -22 |
| Storage temperature | -55...85 °C |
| Suitability for isolation | Yes conforming to EN 60947-3 Yes conforming to IEC 60947-3 |
| Contact position indicator | Yes |
| Main_product_or_component_type | Switch disconnector |
| Operating temperature | -35 |
