Schneider LV426863 ComPact shunt trip, 130 V, pre-wired, discontinued

MPNLV426863
Active

Schneider LV426863 Circuit Breaker Trip Devices — now discontinued, supplied from remaining surplus and broker stock.

$72.39Ref. price · indicative, final on quote
Schneider Electric LV426863 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

LV426863 specifications
ParameterValue
Control typeStandard
Range of productComPacT NSXm
Control signal typeMaintained Impulse
Voltage release typeOpening coil Shunt trip release
Product or component typeVoltage release
Coil voltage110...130 V AC 50/60 Hz 125 V DC
Cable length3.3 ft (1 m)
Wire stripping length0.3 in (8 mm)
Auxiliary connection terminalpre-wired 0...0.001 in² (0...0.8 mm²) AWG 18)stranded copper
Response time< 50 ms
RangeComPact
CategoryUS10DE201136
Impulse duration>= 20 ms
Device short nameMX
Device applicationControl
Operating threshold0.7 Un opening

Product details

Overview

The LV426863 is a Schneider ComPact MX shunt trip release rated 130 V AC/DC, delivered pre-wired with a 0.8 mm² stranded copper cable for direct connection to the control circuit. It is designed for ComPacT NSXm frames (125 A/BD, BG, BJ) and triggers on a maintained or impulse signal with a 50 ms response time.

Comparison with LV426843

The LV426863 shares the same 130 V coil and MX function as the LV426843, but the LV426863 ships pre-wired with a 0.8 mm² stranded copper cable, while the LV426843 uses a spring terminal for field wiring.
