Schneider Electric LV432061
MPNLV432061
Obsolete
LV432061 - CIRCUIT BREAKER by SQUARE D
$685.80Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range | ComPact |
| Standards | EN/IEC 60947-2 UL 508 |
| Network type | AC |
| Trip unit name | MicroLogic 0.3 NA |
| Poles | 3P |
| Pollution degree | 3 conforming to IEC 60947-1 |
| Range of product | ComPact NSX400...630 |
| Network frequency | 50/60 Hz |
| Device application | Distribution |
| Trip unit technology | Electronic |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Trip unit rated current | 400 A at 65 °C |
| Product or component type | Control unit |
| Circuit breaker mounting mode | Fixed |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| Ambient air temperature for storage | -50...85 °C |
| Ambient air temperature for operation | -25...70 °C |
| Instantaneous protection pick-up adjustment type ii | Fixed |
MPN
LV432061
