Schneider Electric LV432605
MPNLV432605
Active
LV432605 - COMPACT NSX400 TO NSX630 by SCHNEIDER ELECTRIC
$35.56 – $76.20Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | ComPact NSX400...630 ComPact NSX400...630 DC |
| Auxiliary contacts type | Standard |
| Product or component type | Auxiliary contact |
| [Ie] rated operational current | AC-12 6 A 110 V AC 50/60 Hz AC-12 6 A 220/240 V AC 50/60 Hz AC-12 6 A 24 V AC 50/60 Hz AC-12 6 A 380/440 V AC 50/60 Hz AC-12 6 A 48 V AC 50/60 Hz AC-12 6 A 480 V AC 50/60 Hz AC-12 6 A 660/690 V AC 50/60 Hz AC-15 0.1 A 660/690 V AC 50/60 Hz AC-15 1.5 A 480 V AC 50/60 Hz AC-15 2 A 380/440 V AC 50/60 Hz AC-15 4 A 220/240 V AC 50/60 Hz AC-15 5 A 110 V AC 50/60 Hz AC-15 6 A 24 V AC 50/60 Hz AC-15 6 A 48 V AC 50/60 Hz DC-12 0.3 A 250 V DC DC-12 0.6 A 110 V DC DC-12 2.5 A 48 V DC DC-12 6 A 24 V DC DC-14 0.03 A 250 V DC DC-14 0.05 A 110 V DC DC-14 0.2 A 48 V DC DC-14 1 A 24 V DC |
| [Ith] conventional free air thermal current | 6 A |
| Mounting mode | Drawout |
| Range | ComPact |
| Category | 01081-INTRA-COMPANY COMPONENTS |
| Minimum load | 100 mA 24 V DC |
| Device short name | early-break contact |
| Device application | Control |
| Auxiliary contacts operation | Early-break |
MPN
LV432605
