Schneider Electric LV833796
MPNLV833796
Active
LV833796 - MASTERPACT MTZ1 DRAWOUT by SCHNEIDER ELECTRIC
$142.24Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Control type | Communicating |
| Voltage release type | Opening coil |
| Product or component type | Voltage release |
| [Un] voltage power supply | 277 V AC 50/60 Hz |
| Threshold tripping voltage | 0.7...1.1 Un on opening |
| Holding power consumption | 4.5 VA |
| Circuit breaker mounting mode | Drawout |
| Maximum response time | 60 ms on opening MasterPact MTZ1 |
| Range | MasterPact |
| Device short name | MX diag & com |
| Device application | Control |
| Signalling function | Electrical push-button activated Ready to close or open Coil powered Error |
MPN
LV833796
