Overview
The LX1D6L6 is a TeSys Deca contactor coil rated for 208 V AC 60 Hz control circuits, drawing 22 W and designed to fit the LC1D80 and LC1D95 contactor frames rated at 95 A. It ships without a built-in suppressor module; the coil dissipates 6 to 10 W at 50/60 Hz and carries a mechanical life of 4 Mcycles.
Selection and comparison
Compared to the LX1D6M6, which runs on 220 V AC 60 Hz at the same 22 W, the LX1D6L6 is the correct choice when the control supply is 208 V AC; the LX1D6M6 suits 220 V AC panels and shares the same contactor compatibility and power draw.
