Schneider Electric LX1G4QLSEA

Schneider LX1G4QLSEA Contactor Coil, 200-500V AC/DC, Obsolet

MPNLX1G4QLSEA
Obsolete

Schneider TeSys contactor coil LX1G4QLSEA, 4-pole, 200-500 V AC/DC, with built-in bidirectional peak limiting.

$421.28Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

LX1G4QLSEA key specifications
ParameterValue
Product or component typeContactor coil
Coil voltage200...500 V AC/DC 50/60 Hz
Control circuit voltage limitsOperational 0.8...1.1 Uc 140 °F (60 °C)) Drop-out 0...0.45 Uc 140 °F (60 °C))
Inrush power in255 VA 480 V AC, 60 Hz
Hold-in power consumption in13.4 VA 480 V AC, 60 Hz
Poles description4P
IP degree of protectionIP20 IEC 60529
Connections - terminalsControl circuit push-in termination 1 0.0003...0.004 in² (0.2...2.5 mm²) solid stranded without cable end sleeve AWG 26...AWG 12 Control circuit push-in termination 1 0.0004...0.004 in² (0.25...2.5 mm²) flexible with cable end sleeve AWG 24...AWG 14 Control circuit push-in termination 2 0.0008...0.002 in² (0.5...1.0 mm²) rigid or stranded with cable end sleeve AWG 20...AWG 18
Pollution degree3 IEC 60947-1
Operating altitude9842.52 ft (3000 m) without derating 5000 m with derating factor
Depth3.7 in (94.0 mm)
Width5.5 in (140.7 mm)

All specifications

LX1G4QLSEA additional specifications
ParameterValue
Height5.7 in (144.5 mm)
Mechanical durability5 Mcycles
StandardsEN/IEC 60947-4-1 UL 60947-4-1A CSA C22.2 No 60947-4-1
RangeTeSys
CategoryUS10I1222328
Operating time20...35 ms opening 40...55 ms closing
Coil technologyBuilt-in bidirectional peak limiting
Quantity per set1
Device short nameLX1G
Maximum operating rate600 cyc/mn 140 °F (60 °C)
Electromagnetic compatibilityEMC immunity conforming to IEC 60947-4-1 Emission tests criteria A conforming to IEC 60947-4-1 Immunity to radiated radio-electrical interference - test level: 20 V/m conforming to EN/IEC 61000-4-3 Voltage dips and interruptions immunity test conforming to SEMI F47
Ambient air temperature for storage-76...176 °F (-60...80 °C)
Ambient air temperature for operation-13...140 °F (-25...60 °C)
Permissible ambient air temperature around the device-40...158 °F (-40...70 °C) at Uc

Product details

The LX1G4QLSEA is a 4-pole contactor coil in the TeSys range, accepting 200-500 V AC/DC with bidirectional peak limiting. It is obsolete; confirm drop-out at 0...0.45 Uc at 60°C.

The opening time of 20...35 ms and closing time of 40...55 ms are typical for a modular contactor coil in this frame; sequence interlocks or safety circuits that depend on timing should allow these windows. Mechanical durability is rated at 5 million cycles — that's not the limit for the entire contactor, only the coil armature, so this component will outlast many electro-mechanical cycles in normal motor-switching duty. The coil accepts control circuit conductors via push-in terminals sized for 0.2 to 2.5 mm² solid or stranded (AWG 26 to 12), and flexible wire with end sleeves from 0.25 to 2.5 mm² (AWG 24 to 14). You can mount this in enclosures up to 3000 m altitude without derating, and up to 5000 m with de-rating. The IP20 protection means a finger-safe enclosure is fine for the panel interior, but not exposed to dripping liquids. Ambient temperature range for operation is -13 to 140°F (-25 to 60°C). The coil draws 155 W DC peak inrush and 255 VA at 480 V AC 60 Hz, holding at 3.4 W DC and 13.4 VA — that is the steady-state burden on the control transformer.

Frequently asked questions

What is the depth of the LX1G4QLSEA?

The depth is 3.7 inches (94.0 mm).

What series does the LX1G4QLSEA belong to?

TeSys.

What compliance documentation is available for the LX1G4QLSEA?

The coil complies with EN/IEC 60947-4-1, UL 60947-4-1A, and CSA C22.2 No 60947-4-1 standards.
