Schneider Electric LX1G4RLSEA

Schneider LX1G4RLSEA TeSys Giga control coil, 4-pole, 200-500 V AC/DC, 375 VA

MPNLX1G4RLSEA
Active

Schneider LX1G4RLSEA Contactor &Amp; Motor Starter Accessories — now discontinued, supplied from remaining surplus and broker stock.

$421.28Ref. price · indicative, final on quote
Schneider Electric LX1G4RLSEA datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

LX1G4RLSEA key specifications
ParameterValue
Product or component typeContactor coil
Coil voltage200...500 V AC/DC 50/60 Hz
Control circuit voltage limitsOperational 0.8...1.1 Uc 140 °F (60 °C)) Drop-out 0...0.45 Uc 140 °F (60 °C))
Inrush power in375 VA 480 V AC, 60 Hz
Hold-in power consumption in14.6 VA 480 V AC, 60 Hz
Poles description4P
IP degree of protectionIP20 IEC 60529
Connections - terminalsControl circuit push-in termination 1 0.0003...0.004 in² (0.2...2.5 mm²) solid stranded without cable end sleeve AWG 26...AWG 12 Control circuit push-in termination 1 0.0004...0.004 in² (0.25...2.5 mm²) flexible with cable end sleeve AWG 24...AWG 14 Control circuit push-in termination 2 0.0008...0.002 in² (0.5...1.0 mm²) rigid or stranded with cable end sleeve AWG 20...AWG 18
Pollution degree3 IEC 60947-1
Operating altitude9842.52 ft (3000 m) without derating 5000 m with derating factor
Depth3.7 in (93.0 mm)
Width7.3 in (185.0 mm)

All specifications

LX1G4RLSEA additional specifications
ParameterValue
Height6.6 in (167.0 mm)
Mechanical durability5 Mcycles
StandardsEN/IEC 60947-4-1 UL 60947-4-1A CSA C22.2 No 60947-4-1
RangeTeSys
CategoryUS10I1222328
Operating time20...35 ms opening 40...55 ms closing
Coil technologyBuilt-in bidirectional peak limiting
Quantity per set1
Device short nameLX1G
Maximum operating rate600 cyc/mn 140 °F (60 °C)
Electromagnetic compatibilityEMC immunity conforming to IEC 60947-4-1 Emission tests criteria A conforming to IEC 60947-4-1 Immunity to radiated radio-electrical interference - test level: 20 V/m conforming to EN/IEC 61000-4-3 Voltage dips and interruptions immunity test conforming to SEMI F47
Ambient air temperature for storage-76...176 °F (-60...80 °C)
Ambient air temperature for operation-13...140 °F (-25...60 °C)
Permissible ambient air temperature around the device-40...158 °F (-40...70 °C) at Uc

Product details

Overview

The LX1G4RLSEA: Certified to EN/IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No 60947-4-1, sealed to IP20, and rated for pollution degree 3 per IEC 60947-1. EMC immunity meets IEC 60947-4-1 criteria A.

Schneider discontinued the LX1G4RLSEA on 2024-12-01. An RFQ confirms available quantity and lead time for line-down or last-time-buy needs.

The 4-pole LX1G4RLSEA draws 14.6 VA at 480 V, 60 Hz, versus the 3-pole LX1G3SLSEA which draws 14.9 VA at the same voltage. The pole count is the deciding factor: pick the LX1G4RLSEA when the contactor requires a 4-pole coil, or the LX1G3SLSEA for a 3-pole build.

MPN
LX1G4RLSEA
