Schneider Electric LX4FG090
MPNLX4FG090
Active
LX4FG090 by SCHNEIDER ELECTRIC
$119.38Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Control circuit type | DC wide range |
| Product or component type | Contactor coil |
| Coil voltage | 110 V DC |
| Control circuit voltage limits | Operational 0.7...1.25 Uc 158 °F (70 °C)) Drop-out 0.2...0.45 Uc 158 °F (70 °C)) |
| Inrush power in | 800 W 68 °F (20 °C)) |
| Hold-in power consumption in | 5 W 68 °F (20 °C) |
| Mechanical durability | 1 Mcycles |
| Range | TeSys |
| Category | 18401-WORLD SERVICE PARTS(CTR ACCESS) |
| Operating time | 30...40 ms closing 30...50 ms opening |
| Coil technology | Without built-in suppressor module |
| Device short name | LX4FG |
| Average resistance | 9.66 Ohm inrush 68 °F (20 °C) 1840 Ohm holding 68 °F (20 °C) |
| Maximum operating rate | 60 cyc/h 158 °F (70 °C) |
| Inductance of closed circuit | 157 H |
| Ambient air temperature for operation | -67...158 °F (-55...70 °C) |
MPN
LX4FG090
