What this drive gives you
Schneider Lexium 28 servo drive, order LXM28AU04M3X, rated 0.4 kW at 220 V, continuous 2.6 A, 16 kHz switching. Accepts 200-240 V single or three-phase. No built-in EMC filter on this variant, so if the installation has long motor cables or shares a panel with sensitive electronics, plan for an external filter. Overvoltage category III means it's rugged enough for fixed industrial installations fed from the mains.
How the ratings translate on the route
Maximum leakage current is 1.3 mA.
Sourcing and lifecycle – it's still in active production
The LXM28AU04M3X is active on the Schneider line – no phase-out notice, no last-time-buy looming. That means you can spec it into a new BOM without worrying about a future swap.
Compact housing – fits a standard panel without hogging space. Supply voltage range is given as 200–240 V -10%/-15% for three-phase and 200–240 V -20%/-15% for single-phase. That lower tolerance on single-phase input could be a gotcha if the line runs low; measure your actual supply before committing.
