Schneider Electric M9XCP157
MPNM9XCP157
Active
MULTI9 COMB 1P57 MOD CUT FOR C60BP|MULTI9 COMB 1P57 MOD CUT FOR C60BP
$296.60 – $681.32Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Connector type | tooth |
| Product or component type | Comb busbar |
| Voltage | 1000 V AC 50/60 Hz UL 508 |
| [Ue] rated operational voltage | 480 V AC 50/60 Hz Ph/Ph 277 V AC 50/60 Hz Ph/N |
| [Ie] rated operational current | 80 A 104 °F (40 °C) |
| Poles configuration for 1 way | 1 x 1P |
| IP degree of protection | IP20 with end-pieces and tooth covers |
| Mounting mode | Horizontal |
| Mounting location | Top tunnel type terminals |
| Connection pitch | 0.7 in (18 mm) |
| Pollution degree | 3 |
| Color | Light gray RAL 7035) |
All specifications
| Parameter | Value |
|---|---|
| Width | 40.4 in (1026 mm) |
| Standards | UL 508 UL 489 EN/IEC 61439-1 |
| Range | Multi9 |
| Category | US10DE200949 |
| Insulation | Insulated |
| 9 mm pitches | 114 |
| Number of ways | 57 ways 1 L |
| Fire resistance | 1760 °F (960 °C) 30 s ) IEC 60695-2-1 |
| Lines description | 1L |
| Device presentation | Cuttable |
| Distance between way | 0.7 in (18 mm) |
| Length in 18 mm modules | 57 |
| Accessory (separate part category) | Connection accessory |
MPN
M9XCP157
