Square D PowerLogic, METSECT80600, solid-core current transformer, 600 A: 80 mA ratio, 600 V insulation voltage, 10 kV impulse withstand.
| Parameter | Value |
|---|---|
| Current transformer type | Standard for cable |
| Product or component type | Current transformer |
| Voltage | 600 V |
| [Uimp] rated impulse withstand voltage | 10 kV |
| Secondary current | 80 mA |
| Line rated current | 600 A |
| Current transformer ratio | 600 A/80 mA |
| Depth | 0.5 in (11.5 mm) |
| Range | PowerLogic |
| Category | US10PL109795 |
| Diameter | Inner 1.3 in (32.5 mm) Outer 2.3 in (57.3 mm) |
Square D METSECT80600 is a PowerLogic solid-core current transformer rated 600 A primary to 80 mA secondary. The 600 V insulation voltage and 10 kV impulse withstand let it land on 600 V class switchgear without a de-rate. It's a standard cable-type CT — inner diameter 1.3 in (32.5 mm), outer 2.3 in (57.3 mm) — so it fits a single large conductor or a bundle up to that opening.
Solid core — conductor must be fed through before termination. Depth is 0.5 in (11.5 mm); secondary current is 80 mA.
Depth is 0.5 in (11.5 mm). That is the dimension along the axis of the conductor, not the outer diameter.
It belongs to the Square D PowerLogic range of metering and monitoring products.
