Schneider Electric METSECTSP5A2020U
MPNMETSECTSP5A2020U
Active
SPLIT CORE CURRENT TRANSFORMER POWERLOGIC UL2808 CT 200A 5A OU|SPLIT CORE CURRENT TRANSFORMER POWERLOGIC UL2808 CT 200A 5A OUTPUT
$123.59 – $144.91Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Network type | AC |
| Current transformer type | Split core |
| Product or component type | Current transformer |
| Secondary current | 5 A |
| Current transformer ratio | 200/5 |
| Primary operational current | 200 A |
| Network frequency | 50 Hz 60 Hz |
| Mounting location | Indoor use only |
| Installation category | III |
| Electrical connection | 8 ft (2.4 m) AWG 16 flying lead |
| Pollution degree | 2 |
| Relative humidity | 0...95 % non condensing |
All specifications
| Parameter | Value |
|---|---|
| Operating altitude | <= 6561.68 ft (2000 m) |
| Depth | 1.12 in (28.45 mm) |
| Width | Internal: 1.4 in (35.6 mm) Total: 4.12 in (104.65 mm) |
| Height | Internal: 1.4 in (35.6 mm) Total: 3.25 in (82.55 mm) |
| Standards | UL 2808 |
| Range | PowerLogic |
| Category | US10PL109661 |
| Insulation | Basic insulation 600 V AC Reinforced insulation 300 V AC |
| Measurement accuracy | 1 % |
| Accessory (separate part category) | Measurement accessory |
| Ambient air temperature for storage | -40...158 °F (-40...70 °C) |
| Ambient air temperature for operation | 5...140 °F (-15...60 °C) |
MPN
METSECTSP5A2020U
