Schneider Electric METSEPM2KDGTLIO22
MPNMETSEPM2KDGTLIO22
Active
Square D METSEPM2KDGTLIO22|Square D METSEPM2KDGTLIO22
$78.74 – $123.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Product or component type | I/O module |
| Output voltage | 40 V DC |
| Voltage state 0 guaranteed | 0...4 V DC |
| Voltage state 1 guaranteed | 18.5...36 V DC |
| Voltage | 2500 V |
| Switching frequency | 2 Hz digital input |
| I/O channels | 2 configurable, <= 20 mA |
| Depth | 0.6 in (14.6 mm) |
| Width | 3.6 in (90.5 mm) |
| Height | 2.09 in (53 mm) |
| Range | EasyLogic |
| Category | US10PL109734 |
| Input impedance | 110 kOhm |
| Output impedance | 50 Ohm |
| Device short name | PM2K2DIDO |
| Device application | Optional expansion module |
| Ambient air temperature for storage | -13...158 °F (-25...70 °C) |
| Ambient air temperature for operation | 14...140 °F (-10...60 °C) |
MPN
METSEPM2KDGTLIO22
