Schneider Electric MGN15710
MPNMGN15710
Obsolete
MGN15710 - FUSE by MERLIN GERIN
$52.34Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product or component type | Fuse-disconnector |
| [Ue] rated operational voltage | 690 V AC |
| Current | 10 A 16 A 20 A 25 A 32 A 12 A 40 A 50 A |
| Poles description | 2P |
| Mounting support | 35 mm symmetrical DIN rail |
| Connections - terminals | Screw clamp terminals1 cable(s) 2.5...25 mm² rigid Screw clamp terminals1 cable(s) 2.5...25 mm² flexible |
| Pollution degree | 3 |
| Depth | 70 mm |
| Width | 53 mm |
| Height | 107 mm |
| Standards | IEC EN 60947-3 |
| Range | Acti9 |
All specifications
| Parameter | Value |
|---|---|
| Fuse size | 14 x 51 mm |
| Fuse curve | AM GG |
| 9 mm pitches | 6 |
| Device short name | SBI |
| Tightening torque | 3.5 N.m |
| Locking options description | Non padlockable |
| Ambient air temperature for storage | -40...80 °C |
| Ambient air temperature for operation | -20...60 °C |
MPN
MGN15710
