Schneider Electric SH30703P1AA4100
MPNSH30703P1AA4100
Active
Square D SH30703P1AA4100 8000RPM Motor
$2,102.50Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Encoder type | Absolute single turn Hiperface DSL |
| Type of cooling | Natural convection |
| Product or component type | Servo motor |
| Supply voltage | 115...480 V |
| Maximum current irms | 17.0 A |
| Output current 3s peak | 17.0 A |
| Continuous stall current | 4.1 A |
| Continuous power | 1330 W |
| Nominal output power | 830 W 230 V single phase 1330 W 400 V three phase 1330 W 480 V three phase |
| Number of motor poles | 3.0 |
| Phases | Three phase |
| Network number of phases | 3 |
All specifications
| Parameter | Value |
|---|---|
| IP degree of protection | IP65 motor: conforming to IEC 60034-5 IP65 shaft bushing: conforming to IEC 60034-5 |
| Mounting support | International standard flange |
| Mounting holes diameter | 0.2 in (5.5 mm) |
| Number of mounting holes | 4 |
| Circle diameter of the mounting holes | 3.2 in (82 mm) |
| Electrical connection | quicklock rotatable right angled connector |
| Key width | 0.2 in (5 mm) |
| Centring collar depth | 0.10 in (2.5 mm) |
| Length | 8.7 in (220 mm) |
| Inertia | 0.0 kg.cm² of brake 0.0 kg.cm² of motor |
| Category | US1PC5218359 |
| Shaft end | Parallel key |
| Shaft length | 1.2 in (30 mm) |
| Holding brake | Without |
| Nominal speed | 3000 rpm 230 V single phase 6000 rpm 400 V three phase 7200 rpm 480 V three phase |
| Rotor inertia | 0.580 kg.cm² |
| Nominal torque | 24.8 lbf.in (2.8 N.m) 230 V single phase 18.6 lbf.in (2.1 N.m) 400 V three phase 18.6 lbf.in (2.1 N.m) 480 V three phase |
| Shaft diameter | 0.6 in (14 mm) |
| Torque constant | 0.72 N.m/A 248 °F (120 °C) |
| Sizing reference | SH30703P |
| Back emf constant | 49 V/krpm 68 °F (20 °C) |
| Device short name | SH3 |
| Motor flange size | 2.8 in (70 mm) |
| Peak stall torque | 100.01 lbf.in (11.3 N.m) 115...480 V three phase |
| Stator inductance | 14.6 mH |
| Stator resistance | 2.7 Ohm |
| Maximum axial force fa | 160 N |
| Temperature copper hot | 266 °F (130 °C) |
| Continuous stall torque | 26.02 lbf.in (2.94 N.m) 115...480 V three phase |
| Maximum radial force fr | 1050 N 1000 rpm |
| Centring collar diameter | 2.4 in (60 mm) |
| Maximum mechanical speed | 8000 rpm |
| Speed feedback resolution | 262144 points/turn |
MPN
SH30703P1AA4100
