Schneider Electric SSD1A335M7C1

Schneider SSD1A335M7C1 Harmony SSR, 35A, 500 V/µs

MPNSSD1A335M7C1
Active

Schneider Electric Harmony SSD1A, 1-phase SSR, 48-600 V AC output, 35 A rated, zero-voltage switching, dv/dt 500 V/µs, DIN rail mount.

$36.83 – $81.09Ref. price · indicative, final on quote
Schneider Electric SSD1A335M7C1 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

SSD1A335M7C1 key specifications
ParameterValue
Range of productHarmony Solid State Relays
Product or component typeModular DIN rail relay
Product configuration typeRelay configuration
Solid state switching typeZero voltage switching
Output voltage48...600 V AC
Pick-Up voltage90 V AC/DC turn-on
Drop-Out voltage5 V AC/DC turn-off
Maximum voltage drop<1.15 V on-state
Control circuit voltage90...280 V AC/DC
Voltage6 kV for input/output circuit 6 kV for input or output to case
Load current0.15...35 A
Current35 A

All specifications

SSD1A335M7C1 additional specifications
ParameterValue
Inrush current1350 A at 60 Hz
Input current range6...10 mA
Maximum leakage current1 mA off-state
Short circuit protection coordinationType 1 Type 2
Load power factor range0.5 with maximum load
Operating frequency47...440 Hz
Phases1 phase
Rated dutyUninterrupted
IP degree of protectionIP20
Mounting support35 mm symmetrical DIN rail conforming to IEC 60715
Connections - terminalsScrew terminals, clamping connection capacity:1...4 mm², AWG 18...AWG 12 for input Screw terminals, clamping connection capacity:1...6 mm², AWG 18...AWG 10 for output
Response time20 ms (turn-on) 30 ms (turn-off)
Pollution degree2
Shock resistance50 gn for 11 ms (peak acceleration) , longitudinal position conforming to IEC 60068-2-27 30 gn for 11 ms (peak acceleration) , vertical position conforming to IEC 60068-2-27
Vibration resistance0.75 mm (f = 10...150 Hz) conforming to IEC 60068-2-6
Depth4.6 in (116.5 mm)
Width0.9 in (22.5 mm)
Height3.7 in (93.2 mm)
StandardsIEC 61373:class B: category 1 IEC 60947-4-3 IEC 62314 IEC 60950-1 CSA C22.2 No 14-13 UL 508
DV (dt)500 V/µs off-state at maximum rated voltage
CategoryUS10CP222375
Test buttonWithout test button
Local signallingLED (green) for control voltage
Device short nameSSD1
Tightening torque1.5...1.7 N.m for control input 13...15 lb.in for control input 1.5...1.7 N.m for load output 13...15 lb.in for load output
Channels1
Device presentationComplete product
Dielectric strength4 kV AC for input/output circuit 4 kV AC for input or output to case
Flammability ratingV-0 conforming to UL 94
Overvoltage categoryIII
Insulation resistance1000 MOhm at 500 V DC
Output switching modeZero voltage switching
Transient overvoltage1200 V
Maximum i2t for fusing8320 A².s for 10 ms 7593 A².s for 8.33 ms
Device form designationForm 5 semiconductor output DOL contactor
Motor controller rating1.5 kW/2 hp at 120 V AC 3.73 kW/5 hp at 240 V AC 7.46 kW/10 hp at 480 V AC
Electromagnetic compatibilityElectrostatic discharge 6 kV criteria A contact discharge conforming to IEC 61000-4-2 Electrostatic discharge 8 kV criteria A air discharge conforming to IEC 61000-4-2 Conducted RF disturbances 10 V, 0.15...80 MHz criteria A level 3 conforming to IEC 61000-4-6 Electrical fast transient/burst immunity test 2 kV, 5/100 kHz criteria B output ports conforming to IEC 61000-4-4 Electrical fast transient/burst immunity test 1 kV, 5/100 kHz criteria B input ports conforming to IEC 61000-4-4 Radiated radio-frequency electromagnetic field immunity test 10 V/m, 80 MHz...1 GHz criteria A conforming to IEC 61000-4-3 Radiated radio-frequency electromagnetic field immunity test 3 V/m, 1.4...2 GHz criteria A conforming to IEC 61000-4-3 Radiated radio-frequency electromagnetic field immunity test 1 V/m, 2...2.7 GHz criteria A conforming to IEC 61000-4-3 Surge immunity test 1 kV criteria A output ports line to line conforming to IEC 61000-4-5 Surge immunity test 2 kV criteria A output ports line to earth conforming to IEC 61000-4-5 Surge immunity test 1 kV criteria A input ports line to line conforming to IEC 61000-4-5 Surge immunity test 2 kV criteria A input ports line to earth conforming to IEC 61000-4-5 Radiated emission environment B for AC input supply conforming to IEC 60947-4-3 Conducted emission environment A for AC input supply conforming to IEC 60947-4-3 Immunity to microbreaks and voltage drops 30 %, 500 ms criteria A conforming to IEC 61000-4-11 Immunity to microbreaks and voltage drops 100 %, 20 ms criteria B conforming to IEC 61000-4-11
Ambient air temperature for storage-40...212 °F (-40...100 °C)
Ambient air temperature for operation-4...176 °F (-20...80 °C)

Product details

Switching characteristics

The SSD1A335M7C1 is a 35 A single-phase solid-state relay from Schneider's Harmony SSD1 family, switching 48–600 V AC loads with zero-voltage turn-on. The dv/dt of 500 V/µs off-state means it withstands fast voltage transients from inductive loads like contactors or small motors without false triggering. Load current range spans 0.15 to 35 A, so you can use it on light resistive loads as well as full-rated heaters. The 20 ms turn-on and 30 ms turn-off times suit general-purpose cycling, not high-speed PWM. Control input accepts 90–280 V AC/DC, picking up above 90 V and dropping out below 5 V. Green LED on the front gives a local status check.

Panel fit

Width is 22.5 mm (0.9 in), a standard single-pole DIN-rail slot. Depth 116.5 mm (4.6 in); height 93.2 mm (3.7 in). Clamping capacity on output terminals goes to 6 mm² (AWG 10), input to 4 mm². Screw terminals, torque 1.5–1.7 N.m on both control and load sides.

Compliance package includes UL 508, CSA C22.2 No 14-13, IEC 60947-4-3, and IEC 61373 for rail shock/vibration (class B, category 1). RoHS and REACH documentation is available with the shipment.

Frequently asked questions

What is the dv/dt rating of the SSD1A335M7C1?

The off-state dv/dt is 500 V/µs at maximum rated voltage, which gives it good immunity to line transients.

What is the depth of the SSD1A335M7C1?

Depth is 4.6 inches (116.5 mm), plus terminal projection. Panel clearance should allow for wiring and finger safety.

What compliance documentation is available for the SSD1A335M7C1?

The relay is certified to UL 508, CSA C22.2 No 14-13, IEC 60947-4-3, IEC 61373 class B, IEC 62314, and IEC 60950-1. RoHS and REACH declarations are provided with each shipment.
