Schneider Electric SSLZRA1
MPNSSLZRA1
Active
Harmony Control 5 Pin 5... 24V dc DIN Rail Relay Socket
$3.15 – $12.99Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | Harmony Solid State Relays |
| Product or component type | Socket for SSL1 |
| Switching voltage | 5 V DC 24 V DC |
| [Ue] rated operational voltage | < 250 V DC |
| [Uimp] rated impulse withstand voltage | 3.6 kV |
| [Ith] conventional free air thermal current | 6 A |
| IP degree of protection | IP20 |
| Connections - terminals | Spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) solid without cable end Spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) flexible with cable end |
| Contact terminal arrangement | Separate |
| Pollution degree | 3 |
| Depth | 3.09 in (78.6 mm) |
| Width | 0.2 in (6.2 mm) |
All specifications
| Parameter | Value |
|---|---|
| Height | 4.06 in (103 mm) |
| Standards | IEC 61984 |
| Marking | CE |
| Category | US10CP221127 |
| Fixing mode | Clip-on (35 mm DIN rail) |
| Shape of pin | Flat |
| Clamping force | 10...40 N |
| Flame retardance | V0 conforming to UL 94 |
| Local signalling | LED (green) for input status |
| Device short name | SSLZ |
| Overvoltage category | III |
| Sale per indivisible quantity | 10 |
| Ambient air temperature for storage | -40...185 °F (-40...85 °C) |
| Ambient air temperature for operation | -40...158 °F (-40...70 °C) |
MPN
SSLZRA1
