The Square D SSP02SBA08D is a Surgelogic surge protection device for 208Y/120 V AC three-phase systems, wired 4-wire (3PH + G). It handles 80 kA per phase of surge current, with an SCCR of 200 kA and MCOV of 150 V—ratings that matter when you're tying into a service entrance with high available fault current. Voltage protection ratings (VPR) are 600 V N-G, 700 V L-N and L-G, and 1000 V L-L. That's the let-through voltage the SPD clamps to during a surge; for a 208Y/120 V panel, 700 V L-N is within typical coordination limits for downstream equipment. Housed in a NEMA 1 enclosure (indoor use only), it's sized for a dedicated panel location. At 17.9 in wide and 6.9 in deep, it occupies a full-width footprint—plan the cabinet layout accordingly.
Square D SSP02SBA08D Surgelogic SPD, 80 kA, 208Y/120V
MPNSSP02SBA08D
Active
Square D Surgelogic SSP02SBA08D, surge protection device, 80 kA per phase, 208Y/120 V AC, NEMA 1, 3-phase 4-wire.
$1,365.00 – $1,859.67Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Type of packing | Box |
| Voltage rating | 208Y/120 V AC |
| Voltage protection rating | 600 V N - G 700 V L-N 700 V L - G 1000 V L - L |
| Surge current | 80 kA per phase |
| Phases | 3 phase |
| IP rating | NEMA 1 |
| Depth | 6.90 in (175.26 mm) |
| Width | 17.90 in (454.66 mm) |
| Height | 4.40 in (111.76 mm) |
| Weight | 8.09 lb(US) (3.67 kg) |
| MCOV | 150 V |
| SCCR | 200 kA |
| Range | Surgelogic |
| Product | Surge protection device |
| Category | US1DE1B08470 |
| Wiring configuration | 4-wire (3PH + G) |
Product details
Frequently asked questions
What is the MCOV of the SSP02SBA08D?
The maximum continuous operating voltage (MCOV) is 150 V. This defines the highest steady-state voltage the SPD can safely withstand without degrading.
What is the SCCR of the SSP02SBA08D?
The short-circuit current rating (SCCR) is 200 kA, making it suitable for service entrances with high available fault current—a key spec for compliance with NEC requirements.
