Schneider SSP04XDSE15A1 Square D 3P Circuit Breaker — now discontinued, supplied from remaining surplus and broker stock.
| Parameter | Value |
|---|---|
| Voltage rating | 480Y/277 V AC |
| Voltage protection rating | 1200 V L-N 1200 V L - G 1200 V L - L 2000 V N - G |
| Current | 20 kA |
| Surge current | 150 A per phase |
| Phases | 3 phase |
| IP rating | NEMA 4X |
| Depth | 4.0 in (101 mm) |
| Width | 6.0 in (152 mm) |
| Height | 6.0 in (152 mm) |
| MCOV | 320 V |
| Product | Surge protection device |
| Category | US1DE1B08466 |
| Wiring configuration | 4-wire |
The SSP04XDSE15A1 is a Square D surge protection device rated for 320 V MCOV on a 3-phase, 4-wire system, switching 150 kA per phase and sealed to NEMA 4X.
An RFQ confirms current availability and lead time for line-down or last-time-buy needs.
