Schneider Electric TM1SHTM4
MPNTM1SHTM4
Active
HUMIDITY AND TEMPERATURE SENSOR MODBUS|HUMIDITY AND TEMPERATURE SENSOR MODBUS
$275.59 – $453.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Output signal | RS485 Modbus RTU +/- 3 % RH RS485 Modbus RTU -40...140 °F (-40...60 °C) +/- 1 °C |
| Range of product | Modicon M171/M172 |
| Accessory (Separate part type) | Probe |
| Supply voltage | 9...28 V AC 9...40 V DC |
| Maximum power consumption | 35 mA |
| IP degree of protection | IP65 |
| Device mounting | Wall mounted |
| Mounting support | Mounting box |
| Electrical connection | Screw-clamp terminals |
| Pollution degree | 2 |
| Relative humidity | 0...100 % |
| Depth | 2.0 in (50.5 mm) |
All specifications
| Parameter | Value |
|---|---|
| Width | 3.9 in (100 mm) |
| Height | 4.8 in (122 mm) |
| Category | US1PC1222537 |
| Fixing mode | 2 fixing points |
| Overvoltage category | I |
| Product specific application | Humidity control |
| Accessory (separate part category) | Measurement accessory |
| Ambient air temperature for storage | -40...158 °F (-40...70 °C) |
| Ambient air temperature for operation | -40...140 °F (-40...60 °C) |
MPN
TM1SHTM4
