The TM5PCDPS is a Profibus DP communication module from the Modicon TM5 family, used to link the automation controller to Profibus DP networks. It's a straightforward bus interface module — no onboard I/O, just the DP connectivity. The module measures 3.0 in (75 mm) deep, 1.5 in (37.5 mm) wide, and 3.9 in (99 mm) tall.
TM5PCDPS Modicon TM5 Profibus DP Module, Obsolete
MPNTM5PCDPS
Obsolete
Modicon TM5 series Profibus DP communication module, TM5PCDPS. CE marked. Dimensions 3.0 in (75 mm) depth, 1.5 in (37.5 mm) width, 3.9 in (99 mm) height.
$194.31Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | Modicon TM5 |
| Product or component type | Profibus DP communication module |
| Shock resistance | 15 gn 11 ms |
| Depth | 3.0 in (75 mm) |
| Width | 1.5 in (37.5 mm) |
| Height | 3.9 in (99 mm) |
| Marking | CE |
| Category | US1PC1222532 |
| Ambient air temperature for operation | 32...131 °F (0...55 °C) without derating horizontal installation) 32...140 °F (0...60 °C) with derating factor horizontal installation) 32...122 °F (0...50 °C) vertical installation) |
Product details
MPN
TM5PCDPS
