Schneider VW3A3409 Encoder Interface Card
MPNVW3A3409
Active
Square D VW3A3409 Encoder Interface Card|Square D VW3A3409 Encoder Interface Card
$135.89Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Output signal | SinCos 10000 lines maximum EnDat 2.1 25 bits maximum SSI Gray or binary with no, odd or even parity, configurable SinCos Hiperface 10000 lines maximum |
| Encoder type | SinCos Hiperface EnDat 2.2 SSI |
| Protection type | Short-circuit protection Overload protection |
| Range of product | Altivar |
| Product or component type | Encoder interface card |
| Supply voltage | 5 V 5...5.5 V) 8 V 8...8.5 V) 12 V 12...12.5 V) |
| Maximum supply current | 0.2 A |
| Clock frequency | 500 kHz fixed |
| Electrical connection | Terminal 0.5 mm² AWG 20) Terminal 0.5 mm² AWG 20) Terminal 0.5 mm² AWG 20) Terminal 0.75 mm² AWG 18) Terminal 0.75 mm² AWG 18) Terminal 0.75 mm² AWG 18) Terminal 1 mm² AWG 17) Terminal 1 mm² AWG 17) Terminal 1 mm² AWG 17) Terminal 1.5 mm² AWG 15) Terminal 1.5 mm² AWG 15) Terminal 1.5 mm² AWG 15) <164.04 ft (50 m), encoder, 200 mA 14.75 V |
| Maximum cable distance between devices | 164.04 ft (50 m) |
| Category | US1CP4C22135 |
| Speed feedback resolution | 2exp(13) maximum |
MPN
VW3A3409
