Schneider VW3A4408 Drive Module
MPNVW3A4408
Active
VW3A4408 by SCHNEIDER ELECTRIC
$692.15Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Range of product | Altivar |
| Product or component type | EMC input filter |
| Power supply voltage | 380...500 V 200...240 V |
| Current | 180 A |
| Maximum earth leakage current | 140 mA at 400 V 50 Hz 193 mA at 480 V 60 Hz 80 mA at 400 V 50 Hz 86.3 mA at 480 V 60 Hz |
| Network number of phases | Three phase |
| IP degree of protection | IP20 IP41 (upper part) |
| Electrical connection | Terminal 150 mm² 300 kcmil |
| Shock resistance | 15 gn for 11 ms conforming to IEC 60068-2-27 |
| Relative humidity | 0...93 % conforming to IEC 68-2-3 |
| Operating altitude | 1000...3000 m with current derating 1 % per 100 m |
| Vibration resistance | 1 gn (f= 13...150 Hz) conforming to IEC 60068-2-6 1.5 mm peak to peak (f= 3...13 Hz) conforming to IEC 60068-2-6 |
All specifications
| Parameter | Value |
|---|---|
| Standards | IEC 61800-3 |
| Tolerance | 10 % |
| Thermal losses | 18 W for ATV21HD55N4 34 W for ATV21HD75N4 23.1 W for ATV21HD30M3X 58 W for ATV61/ATV71 variable speed drives |
| Tightening torque | 25 N.m |
| Product specific application | Radio interference input filter |
| Ambient air temperature for storage | -40...65 °C |
| Ambient air temperature for operation | -10...50 °C |
MPN
VW3A4408
