Schneider VW3A4507 DC Choke
MPNVW3A4507
Obsolete
VW3A4507 - DC CHOKE by SCHNEIDER ELECTRIC
$161.77Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Product or component type | DC choke |
| Maximum voltage drop at rated load | 6 % |
| Max current | 1.65 x nominal current (duration = 60 s) |
| Current | 27.4 A |
| Supply frequency | 50...60 Hz |
| Network number of phases | 3 phases |
| IP degree of protection | IP20 |
| Electrical connection | Earth circuit terminal, connection capacity: 10 mm² (AWG 6) Power supply terminal, connection capacity: 6 mm² (AWG 8) |
| Relative humidity | 0...95 % |
| Operating altitude | 1000...3000 m with current derating 1 % per 100 m |
| Depth | 130 mm |
| Width | 96 mm |
All specifications
| Parameter | Value |
|---|---|
| Height | 134 mm |
| Product weight | 3 kg |
| Thermal losses | 43 W |
| Tightening torque | 1.2...1.4 N.m for earth circuit 0.8...1 N.m for power supply |
| Device application | Reduction of current harmonics |
| Value of inductance | 1.6 mH |
| Ambient air temperature for storage | -40...65 °C |
| Ambient air temperature for operation | 50...60 °C (with current derating 2.2 % per °C) -10...50 °C (without current derating) |
MPN
VW3A4507
