Schneider VW3A7803 Brake Resistor
MPNVW3A7803
Obsolete
VW3A7803 - BRAKE RESISTOR by TELEMECANIQUE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Protection type | Thermal protection via thermal overload relay |
| Range of product | Altivar |
| Average power available | 9.8 kW at 50 °C |
| IP degree of protection | IP23 |
| Electrical connection | M10 bar wire |
| Depth | 540 mm |
| Width | 610 mm |
| Height | 440 mm |
| Ohmic value | 24.5 Ohm |
| Ambient air temperature for storage | -25...75 °C |
| Ambient air temperature for operation | 0...50 °C |
MPN
VW3A7803
