Schneider Electric XPSMFPS01

Schneider Electric XPSMFPS01

MPNXPSMFPS01
Obsolete

Preventa safety PLC power supply, 30A 24V DC

Schneider Electric XPSMFPS01 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

XPSMFPS01 key specifications
ParameterValue
Range of productPreventa Safety automation
Product or component typePreventa safety PLC power supply
Output voltage3.3 V DC / 10 A 5 V DC / 2 A
Supply voltage24 V DC - 15...20 %
Current consumption30 A 24 V DC power supply
IP degree of protectionIP20 with covering plate on unused in rack I/O card slots)
Connections - terminalsRemovable screw clamp terminals, 1 x 0.75...1 x 6 mm² AWG 20) flexible with cable end Removable screw clamp terminals, 1 x 0.75...1 x 6 mm² AWG 20) flexible without cable end Removable screw clamp terminals, 2 x 0.5...2 x 4 mm² AWG 20) flexible without cable end Removable screw clamp terminals, 2 x 0.5...2 x 6 mm² AWG 20) flexible with cable end Removable screw clamp terminals, 1 x 0.75...1 x 16 mm² AWG 19) flexible without cable end Removable screw clamp terminals, 1 x 0.75...1 x 16 mm² AWG 19) solid without cable end Removable screw clamp terminals, 2 x 0.75...2 x 6 mm² AWG 19) flexible without cable end Removable screw clamp terminals, 2 x 0.75...2 x 6 mm² AWG 19) solid without cable end
Pollution degree2
Shock resistance15 gn 11 ms 2 cycles per axis)EN 61131-2
Relative humidity95 % supply not connected
Operating altitude< 6561.68 ft (2000 m)
Vibration resistance1 gn 10...150 Hz) - 10 cycles per axis - EN 61131-2

All specifications

XPSMFPS01 additional specifications
ParameterValue
Electrical shock protection classClass II conforming to IEC 61131-2
StandardsIEC 61131 DIN V 0801 EN 50156 pending DIN V 19250
SupplySELV or PELV EN/IEC 60950
Category22478 - XPS SAFETY PLC
Safety module nameXPS MF60
Safety use categoryCategory 4 maximum EN 954-1 Performance level e EN/ISO 13849-1 SIL 3 EN/IEC 61508
Associated fuse rating32 A
Immunity to microbreaks10 ms
Safety module applicationPower supply
Electromagnetic compatibilityEN/IEC 61131-2
Ambient air temperature for storage-40...185 °F (-40...85 °C) EN/IEC 61131-2
Resistance to electromagnetic fields9.1 V/m (10 V/m) 26...1000 MHz), amplitude modulation 80 % EN/IEC 61000-4-3
Ambient air temperature for operation32...140 °F (0...60 °C)
Resistance to electrostatic discharge4 kV contact EN/IEC 61000-4-2 8 kV on air EN/IEC 61000-4-2
MPN
XPSMFPS01
