Schneider Electric ZB4-BZ106
MPNZB4-BZ106
ZB4-BZ106 - CONTACTS BLOCK by TELEMECANIQUE
$72.53Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Range of product | Harmony XB4 |
| Contact block type | Single |
| Contacts type and composition | 1 NO + 1 NC |
| Voltage withstand | 6 kV IEC 60947-1 |
| Voltage insulation | 600 V 3)IEC 60947-1 |
| Short-Circuit protection | 10 A cartridge fuse gG IEC 60947-5-1 |
| Enclosure_material | Zamak |
| Connections - terminals | Screw clamp terminals, Screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1 |
| Terminals description ISO n°1 | (11-12)NC |
| Shock | 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 |
| Depth | 38.1 |
| Width | 30.48 |
All specifications
| Parameter | Value |
|---|---|
| Height | 48.26 |
| Electrical life cycles | 10000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C 10000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C 10000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C 10000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C 10000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C |
| Mechanical life cycles | 5000000 cycles |
| Standards | IEC 60947-1 IEC 60947-5-4 IEC 60947-5-5 IEC 60947-5-1 CSA C22.2 No 14 JIS C8201-5-1 UL 508 JIS C8201-1 |
| Head_type | Standard |
| IP rating | IP20 IEC 60529 |
| Torque | 0.44 lbf.in (0.05 N.m) NO changing electrical state |
| Package_type | PCE |
| Contacts usage | Staggered contacts |
| Resistance | 5 gn (f= 2...500 Hz) conforming to IEC 60068-2-6 |
| Operating travel | 0.06 in (1.5 mm) NC changing electrical state) 0.1 in (2.6 mm) NO changing electrical state) 0.2 in (4.3 mm) total travel) |
| Positive opening | With IEC 60947-5-1 appendix K |
| Device short name | ZB4 |
| Contact_operation | Overlapping Slow-break |
| Device composition | Fixing collar Body |
| Shape of screw head | Cross Philips no 1 Cross pozidriv No 1 Slotted flat Ø 4 mm Slotted flat Ø 5.5 mm |
| Switching current | 10 |
| Storage temperature | -40...158 °F (-40...70 °C) |
| Protective treatment | TH |
| Electrical reliability | Λ < 10exp(-6) 5 V, 1 mA in clean environment IEC 60947-5-4 Λ < 10exp(-8) 17 V, 5 mA in clean environment IEC 60947-5-4 |
| Sale per indivisible quantity | 1 |
| Main_product_or_component_type | Complete body/contact assembly |
| Operating temperature | -40 |
| Ordering and shipping details (Category) | 22469-PUSHBUTTON,22MM ACCESSORIES-NEW |
MPN
ZB4-BZ106
