Schneider Electric VW3M Series
223 variants · Schneider Electric
Schneider Electric VW3M Series — schneider Industrial Component
Schneider Electric VW3M Series by schneider includes 223 variants for industrial automation, panel building, and machine control. Designed for DIN rail or panel mounting with standardized form factors, these components serve motor control, power distribution, and building infrastructure applications.
Applications
- Control Panels: Motor control centers, distribution boards, and PLC I/O systems in manufacturing and process industries.
- Machine Building: Motor starting, protection, and auxiliary control in automated production and packaging lines.
- Building Services: HVAC, pumping, and lighting control in commercial and industrial facilities.
Selection
Match rated current, voltage, breaking/switching capacity, pole count, and control voltage to application requirements. The manufacturer order code encodes these parameters.
Availability
Standard configurations in distributor inventory. Custom configurations may require additional lead time.
About the Schneider Electric VW3M Series
The Schneider Electric VW3M Series series groups 223 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by main product or component type, accessory separate part type and cable length, so you can match the exact main product or component type your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Schneider Electric VW3M Series variants and discontinued ones from a single page.
Select a variant by
- Main product or component type
- Additionnal I/O module · Connecting cable · Connector · Connector kit · Daisy chain DC bus cable · Encoder cable · Holding brake controller · Power cable
- Accessory separate part type
- Cable · Encoder cable · Jumper cable · Module · Power cable · Preassembled power cordset
- Cable length
- 5 m · 9.8 ft (3 m) · 32.8 ft (10 m) · 49.2 ft (15 m) · 65.6 ft (20 m) · 82.02 ft (25 m) · 164.04 ft (50 m)
Variant comparison
| Parameter | VW3M3103 | VW3M5D6FR30 | VW3M5105R100 | VW3M8222R250 | VW3M8222R500 | VW3M5102R500 |
|---|---|---|---|---|---|---|
| Main product or component type | Holding brake controller | Power cable | Power cable | Connecting cable | Connecting cable | Power cable |
| Accessory separate part type | — | Preassembled power cordset | Preassembled power cordset | Encoder cable | Encoder cable | Preassembled power cordset |
| Cable length | — | 9.8 ft (3 m) | 32.8 ft (10 m) | 82.02 ft (25 m) | 164.04 ft (50 m) | 164.04 ft (50 m) |
Request a quote on any Schneider Electric VW3M Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
