Banner Engineering RPBT

Banner RPBT Mini-Beam Emitter, 30m, 10-30VDC, 6.5 ft

MPN RPBT

Banner RPBT Mini-Beam series photoelectric emitter, 30 m sensing range, 10-30 VDC input, 2 m (6.5 ft) integral cable, no outputs — emitter half only.

$183.44 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

RPBT specifications
ParameterValue
Product typeEmitter
Length6.5 ft

Product details

Half of the optical pair

The Banner RPBT is the emitter half of a Mini-Beam through-beam photoelectric pair, not a standalone switch — the receiver sits across the beam on the opposite side of the sensing field. Input is 10-30 VDC. The 30 m range is the through-beam rating carried by the Mini-Beam emitter spec.

Cable and panel-side wiring

The unit ships with a 6.5 ft (2 m) integral cable, which is enough to reach the gland plate on most sensor columns without splicing — anything beyond that means a field-terminated extension. Because there are no outputs on the emitter, only the DC input pair runs through the cable: no signal wires to mis-wire at the terminal block.

MPN
RPBT
