Crouzet MDE1R05MVA
MPNMDE1R05MVA
Active
RELAY TIME DELAY 9999HRS 5A 250V
$95.04 – $175.34Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Syr-Line TMR48D |
| Termination type | 8-Pin Socket |
| Operating voltage max. | 240 V |
| Operating voltage min. | 100 V |
| Switching voltage - AC | 250 V |
| Switching voltage - DC | 30 V |
| Switching current - AC | 5 A |
| Switching current - DC | 5 A |
| Switching power - AC | 1.25 kVA |
| Contact configuration | 1CO |
| Mode of operation | ON / OFF-Delay;Interval;One Shot;Symmetrical Flashing ON / OFF |
| IP rating | IP20 |
| Time setting max. | 9999 h |
| Time setting min. | 1 ms |
| Number of functions | 6 |
| Number of time ranges | 10 |
MPN
MDE1R05MVA
