Delta AH10PM-5A — PLCs (Programmable Logic Controllers)

Delta AH10PM-5A Motion Control Module, 64K steps, 0.13μs

MPNAH10PM-5A

Delta AH10PM-5A motion control module, 64K-step program capacity, LD instruction @ 0.13μs, 10K/64K word data register, HDC terminal block.

$1,317.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

AH10PM-5A — Specifications
ParameterValue
ModelAH10PM-5A
Data registerD=10K words / W=64K words
Program capacity64K steps
CPU execution speedLD instruction @ 0.13μs
Terminal block typeHDC
Accessories (optional)DVPACAB7E10, DVPAETB-IO24C
Power consumption (Internal)2.7w

Product details

The AH10PM-5A: Data register splits into 10K words for D registers and 64K words for W registers, giving you room for recipe tables, cam profiles, or position arrays without constantly swapping to flash. Power consumption sits at 2.7 W from the internal bus — negligible for the backplane budget, and the HDC terminal block means the wiring stays secure under vibration on a machine frame.

The HDC terminal block is a high-density connector — mates with the DVPACAB7E10 cable or the DVPAETB-IO24C breakout terminal board. No screw terminals on the module itself; plan for a pre-wired harness if you're swapping in the field.

Frequently asked questions

What is the closest functional alternative to the AH10PM-5A?

The AH05PM-5A shares the same program capacity (64K steps), CPU speed (0.13μs), and data register sizes (D=10K words / W=64K words), but uses an EU removable terminal block instead of the HDC connector. If your panel is wired for the HDC block, the AH05PM-5A won't drop in without changing the mating cable or terminal board.

What are the key specs of the AH10PM-5A?

64K-step program capacity, LD instruction at 0.13μs, data register D=10K words / W=64K words, HDC terminal block, 2.7 W internal power consumption.

MPN
AH10PM-5A
