IP65 and ATEX Zone 2 protection
For I/O racks in food processing or chemical zones, the CP-E16-M12X2-5POL carries IP65 sealing and ATEX Zone 2 approval, so it sits directly on the machine without a separate enclosure. The ambient temperature range extends from -5 °C to 50 °C, matching typical factory floor conditions with no derating needed.
16 configurable digital inputs
Each of the 16 inputs accepts PNP or NPN sensors, and 16 LEDs provide instant signal status for every channel—no external probe required during line startup.
M12 double-allocation connectivity
The module uses a single M12 double-allocation plug (5-pin) for both power and I/O, reducing cable count while retaining the ability to daisy-chain modules in a junction box. Output connection is via a socket, and the 1x M9 CP connection handles the bus interface to the Festo CPX/MPA network.
Market availability and sourcing
Classified active with high demand, the CP-E16-M12X2-5POL is widely stocked and easily sourced for both new builds and retrofit projects.
Frequently asked questions
What is the IP rating of the CP-E16-M12X2-5POL?
It is rated IP65, suitable for washdown and dusty environments.
Does the module support both PNP and NPN sensors?
Yes, all 16 digital inputs can be configured as PNP or NPN.
