Festo DSNU-8-10-P-A — Pneumatic Cylinders & Actuators

Festo DSNU-8-10-P-A

MPNDSNU-8-10-P-A
Active

STANDARDS-BASED CYLINDER

$47.84Ref. price · indicative, final on quote
Festo DSNU-8-10-P-A datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026

Specifications

DSNU-8-10-P-A — Identification
ParameterValue
SeriesDSNU
DSNU-8-10-P-A — Configuration
ParameterValue
OperationDouble Acting
TypeLinear Actuator
ConstructionRound Cylinder
DSNU-8-10-P-A — Dimensions
ParameterValue
Stroke length0.394" (10.00mm)
DSNU-8-10-P-A — Pneumatic
ParameterValue
Operating pressure21.8 ~ 145 PSI (1.5 ~ 10 bar)
Connection methodM5
DSNU-8-10-P-A — Mechanical
ParameterValue
Shaft detailExternal Thread M4
FeaturesISO Standardized
DSNU-8-10-P-A — Environmental
ParameterValue
Operating temperature-20°C ~ 80°C
MPN
DSNU-8-10-P-A
