Festo EMMS-ST-87-M-SE-G2
MPNEMMS-ST-87-M-SE-G2
Stepper Motor with Encoder 5.9Nm 550min-1 1.8° NEMA 34
$574.86 – $907.99Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | EMMS-ST |
| Motor type | Hybrid Motor |
| Operating voltage max. | 48 VDC |
| Current | 9.5 A |
| Phases | 2 |
| Resistance per phase | 230 mOhm |
| Width | 85.85 mm |
| Height | 85.85 mm |
| Length | 144.9 mm |
| NEMA size | NEMA 34 |
| Inductance | 2.6 mH |
| Step angle | 1.8 ° |
| Output speed | 550 min<sup>-1</sup> |
| Shaft length | 27 mm |
| Rotor inertia | 1900 gcm² |
| Holding torque | 5.9 Nm |
| Shaft diameter | 11 mm |
| IP rating | IP54 |
MPN
EMMS-ST-87-M-SE-G2
