The Festo SME-1 is a magneto-inductive proximity switch rated for 220 V AC supply with a normally open output. Its 2 ms switching time and 500 Hz frequency make it a solid choice for pneumatic cylinder position sensing on rod-style actuators — the clamping-angle mounting and 2.5 m cable align with typical Festo cylinder installations. The IP66 enclosure handles washdown environments.
Festo SME-1 Proximity Switch, 220V AC, 500Hz
MPNSME-1
Festo SME-1 PROXIMITY SWITCH, magneto-inductive, cable 2.5m, 220V AC, NO, 500Hz, IP66.
$14.50Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Type | PROXIMITY SWITCH |
| Parameter | Value |
|---|---|
| Switching output | Normally Open |
| Switching frequency | 500 Hz |
| Parameter | Value |
|---|---|
| Housing material | Zn Diecast, Epoxy Resin |
| Parameter | Value |
|---|---|
| Model | SME-1 |
| Weight | 0.155 kg |
| Mounting | Using Clamping Angle on Mounting Rod |
| Condition | New |
| Shelf no. | 211107 |
| Dimensions | 15 x 23 x 34 mm |
| Connector type | Cable, 2.5 m |
| Switching time | 2 ms |
| Operating voltage | 220 V AC |
| Type of protection | IP66 |
| Measuring principle | Magneto Inductive |
| Ambient operating temperature | -20 … 60°C |
| Max. permissible voltage peaks | 550 V AC |
Product details
MPN
SME-1
