Honeywell — General Purpose Relays

Honeywell General Purpose Relays — 4 part numbers with specifications and datasheets. Filter by key specs and request a quote on AO Ctrl.

AC Contact Rating
10 A @ 125 V10 A @ 250 V · 15 A @ 125 V15 A @ 250 V · 15 A @ 125 to 480 V · 15 A @ 240 V
Contact Form
SPST · SPDT · DPST · DPDT
DC Contact Rating
15 A @ 28 V · 20 A @ 28 V · 18 A @ 28 V · 0.25 A @ 250 V0.5 A @ 125 V
Number of Connections
2 · 3 · 4 · 6
Overall Depth
1.12 in · 1.13 in · 0.7 in · 0.07 in
Overall Height
2.3 in · 2.49 in · 1 in · 0.95 in
Overall Width
0.62 in · 0.89 in · 1.94 in · 2 in
Switch Function Configuration
Momentary On/Off · Momentary On/Off/Momentary On · On/Off · Momentary On/Off/On
