Littelfuse 201-100-DPDT-60MS — Relay Sockets

Littelfuse 201-100-DPDT-60MS

MPN201-100-DPDT-60MS
Obsolete

3-PH 11-PIN PLUG-IN VM / 95 -

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

201-100-DPDT-60MS — Identification
ParameterValue
Series201-XXX-DPDT
201-100-DPDT-60MS — Function & Sensing
ParameterValue
TypeVoltage Sensing AC
Trip range95 ~ 120V AC
Trip statusEnergized Low
201-100-DPDT-60MS — Contacts & Switching
ParameterValue
Contact configurationDPDT (2 Form C)
Contact rating10A @ 240VAC
Output typeRelay
201-100-DPDT-60MS — Coil / Input
ParameterValue
Supply voltage95 ~ 120VAC
201-100-DPDT-60MS — Timing & Performance
ParameterValue
Delay timeFixed, 0.50 Sec
201-100-DPDT-60MS — Mechanical & Mounting
ParameterValue
Mounting typeSocketable
201-100-DPDT-60MS — Environmental & Durability
ParameterValue
Operating temperature range-40°C~70°C
MPN
201-100-DPDT-60MS
