Littelfuse L50S500
MPNL50S500
500A, 500VAC/450VDC, L50S Very Fast Acting Fuse|500 Amp Fuse, Semiconductor, Brand or Series: L50S, Type: Bolt Mount, Voltage Rating: 500 VAC, 450 VDC, Interrupting Rating: VAC 200000 RMS Amp VDC 20000 Amp, Dimensions: 1 1/2 Diameter x 4 11/32 Length Inch, Material: Fiberglass Body, Features: Very Fast Acting.
$213.16Ref. price · indicative, final on quote
StockContact for availability
Lead timeCall for availability wk
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Type | Semi Conductor |
Ratings
| Parameter | Value |
|---|---|
| Current (A) | 500 |
| Voltage (AC) | 500 |
Performance
| Parameter | Value |
|---|---|
| Speed | Very Fast Acting |
Protection & Breaking
| Parameter | Value |
|---|---|
| DC interrupting rating | 20 kA |
Mechanical
| Parameter | Value |
|---|---|
| Mounting style | Bolt In |
| Length | 4 11/32 in |
Approvals
| Parameter | Value |
|---|---|
| Standards / approvals | California Proposition 65 |
Other specifications
| Parameter | Value |
|---|---|
| Diameter | 1 1/2 in |
| Volts DC | 450 |
MPN
L50S500
