Littelfuse LSR-230 — General Purpose Relays

Littelfuse LSR-230

MPNLSR-230
Active

LOAD SENSOR/ 230V/ 2-100A/ 20-

$135.93 – $173.20Ref. price · indicative, final on quote
Littelfuse LSR-230 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

LSR-230 — Identification
ParameterValue
SeriesLSR-XXX
LSR-230 — Contacts & Switching
ParameterValue
Contact rating at voltage10A @ 240VAC
LSR-230 — Coil & Supply
ParameterValue
Supply voltage range230VAC
LSR-230 — Function & Indication
ParameterValue
Trip range2 ~ 100A DC
TypeCurrent Sensing AC
Delay timeNo Delay
LSR-230 — Mechanical
ParameterValue
Mounting typeChassis Mount
LSR-230 — Environmental
ParameterValue
Operating temperature range-20°C ~ 70°C
LSR-230 — Other specifications
ParameterValue
CircuitSPDT (1 Form C)
Output signalRelay
Trip statusEnergized High/Low
MPN
LSR-230
