Littelfuse TDB230AL — Time Delay Relays

Littelfuse TDB230AL

MPNTDB230AL
Active

RELAY TIME DEL 1023SEC 10A 120V

$104.66Ref. price · indicative, final on quote
Littelfuse TDB230AL datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026

Specifications

TDB230AL — Identification
ParameterValue
Relay typeMechanical Relay
SeriesTDB
TDB230AL — Timing
ParameterValue
FunctionOff-Delay
Delay time range1 Sec ~ 1023 Sec
Timing adjustment methodDIP Switches
Timing initiate methodInput Voltage, Trigger Signal
TDB230AL — Electrical
ParameterValue
Supply voltage230VAC
TDB230AL — Output / Contacts
ParameterValue
Contact rating10A @ 120/240VAC
Contact configurationSPDT (1 Form C)
TDB230AL — Mechanical
ParameterValue
Termination stylePlug In, 8 Pin (Octal)
Mounting typeSocketable
MPN
TDB230AL
