Littelfuse TDSH120AL
MPNTDSH120AL
Active
RELAY TIME DEL 10230SEC 10A 120V
$146.41Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026
Specifications
| Parameter | Value |
|---|---|
| Relay type | Mechanical Relay |
| Series | TDSH |
| Parameter | Value |
|---|---|
| Function | One Shot |
| Delay time range | 10 Sec ~ 10230 Sec |
| Timing adjustment method | DIP Switches |
| Timing initiate method | Input Voltage, Trigger Signal |
| Parameter | Value |
|---|---|
| Supply voltage | 120VAC |
| Parameter | Value |
|---|---|
| Contact rating | 10A @ 120/240VAC |
| Contact configuration | SPDT (1 Form C) |
| Parameter | Value |
|---|---|
| Termination style | Plug In, 8 Pin (Octal) |
| Mounting type | Socketable |
MPN
TDSH120AL
