Mitsubishi FX3G-422-BD Communication Board
MPNFX3G-422-BD
RS-422 Communication Function Expansion Board
$23.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Withstand voltage | Non-isolated between communication line and the PLC main unit (Please do not withstand voltage test) |
| Frequency | 57 ~ 150Hz : Acceleration: 9.8m / s2 X, Y, Z each direction 10 times (for a total of each 80 minutes) |
| Direct mounting at the time frequency | 10 ~ 57Hz : Half amplitude: 0.075mm X, Y, Z each direction 10 times (for a total of each 80 minutes) |
| Vibration resistance when the DIN rail mounting frequency | 10 ~ 57Hz : Half amplitude: 0.035mm X, Y, Z each direction 10 times (for a total of each 80 minutes) |
| Communication speed | 9600/19200/38400/57600/115200 (bps) |
| Communication system | Half-duplex bi-directional |
| Communication procedure | Programming communication |
| External device connection method | MINI DIN 8pin (female) |
| Operating temperature | 0 ~ 55 °C ····· operation, -25 ~ 75 °C ····· during storage |
| Relative humidity | 5 ~ 95% RH (non-condensing) ...... operation |
| Shipping weight | 1 Kg |
| Transmission standard | It conforms to the RS-422 standard |
All specifications
| Parameter | Value |
|---|---|
| Impact | 147m / s2, duration of action 11ms, X at half-sine pulse, Y, Z directions 3 times each |
| Anti-noise | Noise voltage 1,000Vp-p, noise width 1μs, due to rising 1ns, cycle 30 ~ 100Hz of noise simulator |
| Advanced use | 2,000m or less can not be used under the pressurized environment to more than atmospheric pressure. There is a possibility of failure. |
| Manufacturer | Mitsubishi Electric |
| Use atmosphere | Corrosive, there is no flammable gas, conductive dust (dust) that is not terribly |
| Apply sequencer | FX3S, FX3G FX3S when connected, can not be used in conjunction function expansion board and FX3S-CNV-ADP. |
| Insulation method | Non-insulated (between the communication line and the CPU) |
| O occupied points | 0 points (no relation to the maximum input and output points of the sequencer) |
| Estimated lead time | 1 - 10 Working Days |
| Insulation resistance | Non-isolated between communication line and the PLC main unit (Please do not insulation resistance test) |
| Transmission distance | Up to 50m |
MPN
FX3G-422-BD
