Mitsubishi Electric FX3G Series programmable controller, model FX3G-60MR/D, 60 integrated I/O (36 inputs, 24 relay outputs), 24 VDC supply, 0.85 kg, 8.6 x 17.5 x 9.0 cm.
| Parameter | Value |
|---|---|
| Weight | 0.85 Kg |
| Parameter | Value |
|---|---|
| Output signal | Relay |
| Product type | FX3G Series Programmable Controller |
| Power supply | 24VDC |
| Integrated inputs | 36 |
| Integrated outputs | 24 |
| Dimensions (L x w x h) | 8.6 cm x 17.5 cm x 9 cm |
| Integrated inputs (Outputs) | 60 |
The Mitsubishi Electric FX3G-60MR/D is a 60-point programmable controller with 36 integrated inputs and 24 relay outputs, running on a 24 VDC supply. The relay outputs handle higher inrush loads — solenoids, contactors, small motor starters — without the snubbing a transistor output would need. This makes it a fit for panels where the field devices are inductive and the environment is gritty.
The estimated lead time is usually 1–10 working days.
No — the FX5-20PG-P is a 2-axis positioning module with a different form factor, power supply, and I/O architecture. The FX3G-60MR/D is a standalone PLC base unit; a panel re-spin is required.
