Mitsubishi Electric FX3U-128MT/ESS

Mitsubishi FX3U-128MT/ESS PLC, 64 inputs 64 transistor outpu

MPN FX3U-128MT/ESS

Mitsubishi MELSEC-F Series, FX3U-128MT/ESS, PLC base unit, 64 DC inputs + 64 transistor source outputs, 256 local I/O, 100-240 VAC, 64K steps, IP10.

$454.00 – $1,109.73 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

FX3U-128MT/ESS specifications
ParameterValue
SeriesMELSEC-F SERIES
Output signalTRANSISTOR
Product typeFX3U
IP ratingIP10
Weight1499 kg

Product details

The Mitsubishi FX3U-128MT/ESS is a MELSEC-F series PLC base unit with 64 DC 24 V inputs and 64 transistor source outputs, handling up to 256 local I/O points (384 with remote expansion). It runs on 100-240 VAC, consuming 65 W, and offers a 64K step program memory with a cycle time of 65 ns for LD instructions and 642 ns for MOV. Built-in RS-422 is standard; USB is an option. The unit is expandable via the MELSEC-F extension bus, accepts buffer battery-backed RAM, and is rated IP10 for basic environmental protection. Its operating range is 0–55 °C.

The closest functional peer within the current Mitsubishi PLC line is the FX5U-64MT/DS, which is part of the newer iQ-F series. The FX3U-128MT/ESS offers 64 inputs and 64 outputs, while the FX5U-64MT/DS provides 32 inputs and 32 outputs.

MPN
FX3U-128MT/ESS
