FX3U-2HSY-ADP - Mitsubishi Electric
MPNFX3U-2HSY-ADP
High speed output adapter FX 3 U - 2 HSY - ADP
$219.00 – $474.98Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Withstand voltage | High-speed output Between the output terminal of the special adapter and the earth terminal of the PLC main unit: AC 500 V for 1 minute |
| Power-supply voltage | DC 5 V 30 mA ( internal power supply from the sequencer ) DC 24 V 60 mA ( internal power supply from the service power supply of the sequencer) |
| Absolute position detection (ABS current value reading) | Use sequencer's ABS command |
| Frequency | 57 to 150 Hz : Acceleration: 9.8 m / s 2 10 times in X, Y, Z directions (80 minutes in total) |
| Output frequency | 200 kHz |
| Maximum frequency | 200 kHz |
| Direct installation frequency | 10 to 57 Hz : One amplitude: 0.075 mm X, Y, Z 10 times in each direction (80 minutes in total) |
| Anti-vibration when DIN rail is installed frequency | 10 to 57 Hz : One amplitude: 0.035 mm X, Y, Z 10 times in each direction (80 minutes in total) |
| Operating temperature | 0 to 55 ° C. ... Operating, -25 to 75 ° C. ..... Save |
| Use altitude | Can not be used in an environment pressurized to 2000 m or less under atmospheric pressure. It may break down. |
| Relative humidity | 5 to 95% RH (noncondensing).... in operation |
| Shipping weight | 1 Kg |
All specifications
| Parameter | Value |
|---|---|
| Mass | 0.08 Kg |
| Output form | You can select forward rotation (FP) / reverse rotation (RP) or pulse (PLS) / direction (DIR). |
| Control unit | pulse |
| Manufacturer | Mitsubishi Electric |
| Output method | Differential line driver output |
| Position data | 1 point (set by sequence program) |
| Noise immunity | Noise voltage with 1,000 Vp-p, noise width 1 μs, rising 1 ns, with noise si |
| Use atmosphere | There is no corrosive property, flammable gas, conductive dust (dust) is not serious |
| Impact resistance | 147 m / s 2 , working time 11 ms, three times in X, Y, Z directions with a sine half-wave pulse |
| Positioning range | Depending on the sequence program |
| Pulse output form | Pulse train + direction, forward rotation / reverse rotation pulse train |
| Estimated lead time | 1 - 10 Working Days |
| Pulse output method | Differential line driver system |
| Operation indication | LED on when output is ON |
| Programming language | Sequence program |
| Application sequencer | FX3U |
| Insulation resistance | High-speed output Between the output terminal of the special adapter and the earth terminal of the programmable controller main body: 500 MV DC, 5 MΩ or more with the insulation resistance meter |
| Number of control axes | Independent 2 axes (2 units connected and independent 4 axes controllable) |
| Number of output points | When 4 points are connected: Y000, Y001, Y004, Y005 are assigned. When two units are connected: Y000 to Y007 are assigned. (FX 3 U - 2 HSY - ADP Output terminals of the sequencer body with the same number can not be used.) |
| Number of occupied i (O points) | When connecting one FX 3 U - 2 HSY - ADP, use the outputs Y000, Y001, Y004, Y005 of the basic unit. In the case of connecting two units, use the outputs Y000 to Y007 of the basic unit. |
| Acceleration (deceleration processing) | Depending on the sequence program |
MPN
FX3U-2HSY-ADP
