Mitsubishi Electric FX5UC-64MT/D

Mitsubishi FX5UC-64MT/D CPU Module, 64 I/O points, Sink I/O

MPNFX5UC-64MT/D

Mitsubishi MELSEC iQ-F, CPU Module, FX5UC-64MT/D, 64 points (32 input + 32 output), 24 V DC sink input, transistor sink output, connector type.

$1,048.00 – $1,732.71Ref. price · indicative, final on quote
Mitsubishi Electric FX5UC-64MT/D datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

FX5UC-64MT/D specifications
ParameterValue
Input type24 V DC (sink)
Output signalTransistor (sink)
Product typeCPU Module
Input (output connection type)Connector
5 v DC power supply720 mA
24 v DC power supply500 mA
Power supply capacity5 v DC power supply720 mA24 V DC power supply : 500 mA
Shipping weight1.5 Kg
Total no.of points64 points
Estimated lead time1-10 working days.
No. of input points32 points
No. of output points32 points
No. of input (output pointsTotal no.of points)64 pointsNo. of input points : 32 pointsNo. of output points : 32 points

Product details

CPU module for compact control

The Mitsubishi FX5UC-64MT/D is the 64-point CPU module in the MELSEC iQ‑F FX5UC series, packing 32 sink inputs and 32 sink outputs on a connector‑type base unit. With a 5 VDC draw of 720 mA and a 24 VDC draw of 500 mA, it slots into the same backplane power budget as its smaller stablemates — a straight swap for the FX5UC‑32MT/D if you need the extra I/O. The sink‑type 24 VDC inputs and transistor sink outputs suit it for high‑speed discrete control in packaging, material handling, or assembly cells where relay longevity is a concern. Connector I/O means pre‑fab harnesses rather than individual screw terminals; factor that into your panel layout cycle.

Frequently asked questions

Can the FX5UC-64MT/D drop into a panel designed for the FX5UC-32MT/D?

Yes. Both modules share the same physical footprint, power supply requirements (720 mA at 5 VDC, 500 mA at 24 VDC), and connector type. The swap is straightforward as long as wiring accommodates the additional 16 inputs and 16 outputs.

What is the closest functional sibling to the FX5UC-64MT/D?

The FX5UC-32MT/D is the same series with half the I/O (16 inputs, 16 outputs). It is the direct peer in the FX5UC family, not a second-source but a lower-I/O variant.

MPN
FX5UC-64MT/D
