Mitsubishi FX5UC-96MT/D CPU Module, 96 I/O (48 in, 48 out)

Name: FX5UC-96MT/D
Brand: Mitsubishi Electric
SKU: FX5UC-96MT-D
Availability: LimitedAvailability
Author: Reseller Rui

MPNFX5UC-96MT/D

Mitsubishi FX5UC-96MT/D CPU Module, 96 I/O points (48 inputs, 48 outputs), 24 V DC sink input, transistor sink output, connector connection.

$1,517.00Ref. price · indicative, final on quote

Request quote

Mitsubishi Electric FX5UC-96MT/D datasheet (PDF)

StockContact for availability

MOQ1 pcs

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

How we verify every order →

Specifications

FX5UC-96MT/D specifications
Parameter	Value
Input type	24 V DC (sink)
Output signal	Transistor (sink)
Product type	CPU Module
Input (output connection type)	Connector
5 v DC power supply	720 mA
24 v DC power supply	500 mA
Power supply capacity5 v DC power supply	720 mA24 V DC power supply : 500 mA
Shipping weight	1.5 Kg
Total no.of points	96 points
Estimated lead time	1-10 working days.
No. of input points	48 points
No. of output points	48 points
No. of input (output pointsTotal no.of points)	96 pointsNo. of input points : 48 pointsNo. of output points : 48 points

Product details

At a glance: what this CPU module delivers

The Mitsubishi FX5UC-96MT/D packs 96 I/O points — 24 V DC sink inputs and transistor sink outputs, all on connector-type interfaces — into a compact footprint suited for high-density cabinet layouts.

The FX5U-80MT/DS also draws more 5 V supply current (1100 mA vs 720 mA), so a direct swap without checking the power budget could overload the backplane.

Current production and sourcing reality

Lead time is typically 1–10 working days, making it a reliable choice for both new builds and urgent line-down replacements.

Frequently asked questions

What is the input type?

The inputs are 24 V DC sink-type.

What is the output type?

The outputs are transistor sink-type.

Will the FX5UC-96MT/D drop into a panel originally wired for an FX5U-80MT/DS?

No. The FX5UC-96MT/D uses connector-type I/O, while the FX5U-80MT/DS uses screw terminal blocks. The panel would need to be rewired with connector cables.
