Mitsubishi Electric GT16M-R2 — HMI Operator Interfaces

Mitsubishi Electric GT16M-R2 RGB Input Unit, 2 channels

MPNGT16M-R2

Mitsubishi Electric GT16M-R2 RGB Input Unit, 2 channels, analog RGB (XGA/SVGA/VGA), 1024 x 768 to 640 x 480, D-sub 15 pin female, 0.75A internal draw.

$224.00 – $491.49Ref. price · indicative, final on quote
Mitsubishi Electric GT16M-R2 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

GT16M-R2 — Mechanical
ParameterValue
Weight0.17 Kg
GT16M-R2 — Other specifications
ParameterValue
Product typeRGB Input Unit
Size1024 768 (refresh rate 60Hz)800 600 (refresh rate 60, 72, 75Hz)640 480 (refresh rate 60, 72, 75, 85Hz)
RGB input methodAnalog RGB(XGA;1024 768, SVGA;800 600, VGA;640 480)
Internal current consumption0.75A
Number of video input channels2 channels
Connector for external connectionD-sub 15 pin: female

Product details

Two-channel analog RGB capture for an HMI backplane

The Mitsubishi Electric GT16M-R2 is an RGB Input Unit that brings an external analog RGB video source — projector, PC, or analog monitor feed — onto a GT16-series HMI display, with two channels handled through a single D-sub 15 pin female connector. Internal draw is 0.75 A from the GT16 backplane, so power headroom on the host HMI is the only electrical constraint — there is no field wiring beyond the VGA cable itself.

Mature line and how it is sourced

Lifecycle for the GT16M-R2 reads as mature rather than active-introduction: the part is still orderable, but new design-in activity has slowed, and panel builders typically treat it as a long-lead spare rather than a greenfield component. Lead time is quoted at 1 to 10 working days against the BOM, which is consistent with a part pulled from finished-goods or controlled-channel inventory rather than a fresh production run — order placement is the sourcing trigger, not shelf stock.

Frequently asked questions

Where can I buy GT16M-R2 and how do I get a price?

The order code GT16M-R2 is sourced against the BOM through independent industrial distribution; pricing and current availability are confirmed at RFQ. No channel- or partnership-level claim is made — only that the part is quoted to order on the listed code.

What video resolutions does the GT16M-R2 accept?

The unit accepts those three timings only — a source running outside those timings will not display cleanly through this module.
